Model: U7-IW

SKU Code: 0036990

Ubiquiti UniFi UAP U7 In-Wall Access Point

Currently Not Available

€189.00

Offers available in Stores only

€170.10

Description

Overview
The Ubiquiti U7-IW UniFi In-Wall Wi-Fi 6 Access Point is engineered for seamless integration into wall spaces to provide high-speed, reliable wireless networking. Designed for residential and commercial installations, it delivers stable, high-capacity dual-band Wi-Fi 6 connectivity with efficient Power over Ethernet (PoE) support, eliminating the need for additional power cables.

Specifications

Overview
Dimensions: 137 x 98.7 x 30.2 mm
WiFi Standard: WiFi 7
Spatial Streams: 4
Coverage Area: 115 m²
Max. Client Count: 200+
Uplink: 2.5 GbE
Mounting: Wall (Metal Wall Mount Included)
Power Method: PoE, PoE+ (Required for PoE output)

Performance
MIMO
5 GHz: 2 x 2 (DL/UL MU-MIMO)
2.4 GHz: 2 x 2 (DL/UL MU-MIMO)

Max. Data Rate
5 GHz: 4.3 Gbps (BW240)
2.4 GHz: 688 Mbps (BW40)

Antenna Gain
5 GHz: 8 dBi
2.4 GHz: 4 dBi

Max. TX Power
5 GHz: 24 dBm
2.4 GHz: 23 dBm
Max. BSSIDs: 8 per Radio

Supported Data Rates
802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Features
Wireless Meshing: ✓
Band Steering: ✓
802.11v BSS Transition Management: ✓
802.11r Fast Roaming: ✓
802.11k Radio Resource Management (RRM): ✓
Advanced Radio Management: ✓
Passpoint (Hotspot 2.0): ✓
Captive Hotspot Portal:
  • Custom Branding Landing Page: ✓
  • Voucher Authentication: ✓
  • Payment-Based Authentication: ✓
  • External Portal Server Support: ✓
  • Password Authentication: ✓
  • Guest Network Isolation: ✓
Private Pre-Shared Key (PPSK): ✓
WiFi Speed Limiting: ✓
Client Device Isolation: ✓
WiFi Schedules: ✓
RADIUS over TLS (RadSec): ✓
Dynamic RADIUS-assigned VLAN: ✓

Hardware
Max. Power Consumption: 13W (Excluding PoE output)
Supported Voltage Range: 42.5—57V DC
Networking Interface: (3) 2.5 GbE RJ45 ports
Weight: 400 g
Management: Ethernet
Built-In Switch:
  • (1) PoE+ input
  • (1) PoE output
Enclosure Material: Polycarbonate, aluminum alloy
Mount Material: Aluminum alloy
LEDs: System: White/Blue
Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
NDAA Compliant: ✓
Certifications: CE, FCC, IC, SRRC, Anatel: 03909-25-08356
Ambient Operating Temperature: -30 to 40° C
Ambient Operating Humidity: 5 to 95% noncondensing

Software
Application Requirements
UniFi Network: Version 9.0.114 and later
Mobile App:
  • iOS™ version 10.20.2 and later
  • Android™ version 10.21.7 and later

Warranty and Returns Policy
