Model: U6-MESH

SKU Code: 0030599

Ubiquiti UniFi UAP U6 Mesh Access Point

Sleek, indoor/outdoor WiFi 6 AP with 6 spatial streams designed for mesh applications.

Quantity



€229.00

€239.00

In stock

Stock in Birkirkara & Zejtun

Description

Overview
Sleek, indoor/outdoor WiFi 6 AP with 6 spatial streams designed for mesh applications.

Features
  • WiFi 6
  • 6 spatial streams
  • 140 m² (1,500 ft²) coverage
  • 300+ connected devices
  • Powered using PoE
  • GbE uplink
  • Versatile tabletop, wall, and pole mounting
  • Weatherproof (outdoor exposed)*

Specifications

Mechanical
Dimensions: Ø48.5 x 159.5 mm
Weight: 400 g
Enclosure material: Polycarbonate, aluminum
Mount material:  Polycarbonate
Weatherproofing: IPX5

Hardware
Networking interface: (1) GbE RJ45 port
Management interface: Bluetooth/Ethernet
Power method: PoE
Power Supply: UniFi PoE switch, 48V, 0.32A PoE adapter (Included)
Supported voltage range: 44—57V DC
Max. power consumption: 11.4W
Max. TX power
  • 2.4 GHz: 22 dBm
  • 5 GHz: 26 dBm
MIMO
  • 2.4 GHz: 2 x 2 (UL MU-MIMO)
  • 5 GHz: 4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz: 573.5 Mbps
5 GHz: 4.8 Gbps
Antenna gain
2.4 GHz: 3 dBi
5 GH: 5 dBi
LED: White/blue
Button: Factory reset
Mounting: Wall, desktop, pole (Included),Ceiling (Optional)
Operating temperature: -30 to 60° C
Operating humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC

Software
WiFi standards
  • 802.11a/b/g/n/ac/ax
Wireless security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID: 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest traffic isolation: Supported
Concurrent clients: 300+
Zero-wait DFS: Yes
*Supported with upcoming firmware versions.

Supported Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4): 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements
UniFi Network: Version 6.2.51 and later
