Model: DGS-1100-26MPV2/E

SKU Code: 0034058

D-Link DGS-1110-26MPV2 24-Port POE Gigabit Smart Switch

Simple. Easy to use. Smart

Quantity



€479.00

In stock

Call for Availablity

Description

User-friendly web interface
The user friendly web interface of the DGS-1100 switches allows you to conveniently control layer 2 functions, such as VLANs, Spanning Tree Protocol (STP) and Link Aggregation (static). Thanks to its strong security features, such as IGMP snooping, static MAC addresses, and storm control, the DGS-1100 series is versatile in environments that require quick and easy deployment solutions without additional complexity.

Easy to set up and manage
The free D-Link Network Assistant (DNA) displays all connected devices and facilitates initial configuration. The free D-View 7 Network Management System includes a license for 25 nodes and 2 samples as well as full access to all management tools. With optional upgrade licenses, you can expand your network and analytics.

Monitoring mode
When you select monitoring mode in the web interface, its user-friendly features are available to help you conveniently manage your surveillance network. In this mode, the surveillance devices are automatically detected and combined in a separate automatic monitoring VLAN to process their traffic safely and efficiently.

Manage Anywhere, Anytime
Remote setup & management is easy, and can be done from anywhere.

MaxPoE with capacities of up to 370 W
The DGS-1100 Smart Series includes a range of high-power PoE enabled switches for businesses that want to run a larger number of VoIP phones, wireless access points or network cameras.

Easy troubleshooting
The DGS-1100 series offers loopback detection and cable diagnostics that help network administrators find and fix network problems quickly and easily.
With Loopback Detection, loops generated by a specific port are detected, which automatically switches off the affected port. With the cable diagnostic function, network administrators can quickly check the quality of copper cables, determine the cable type and detect cable errors.

D-link green technology
Thanks to D-Link Green technology, the DGS-1100 Smart Series can save power without functional restrictions. Most of the product family works silently and energy-efficient without fans. All switches meet IEEE 802.3az standard and provide connection status detection as well as PoE by schedule (with the exception of models DGS-1100-05PD and DGS-1100-08P).

Specifications

Technical Specifications
 Product Type: Switch
 PoE Power Budget: 370W
 Ethernet Switch Type: Layer 2 Managed
 Ports: 26
 RJ45 Ports: 26
 PoE Ports: 24
 Fibre Ports: 2
 Fibre Port Type: SFP
 Network Speed: 1 Gbps
 Series: DGS-1100 v2
 Mounting Type: Rack Mount
 Operating Voltage Min. - AC: 100 V
 Operating Voltage Max. - AC: 240 V
 Operating Temperature Min.: -5 °C
 Operating Temperature Max.: 50 °C
Dimensions(mm): 440 x 208 x 44mm

Warranty and Returns Policy
