DJI RS 5 Combo Gimbal

Name: DJI RS 5 Combo Gimbal
Brand: DJI
SKU: 0040231
Price: 719.00 EUR
Availability: InStock

Lead the Scene

In stock

In Stock - Currently online only

Quantity

€719.00

Offers available in Stores only

GO Freedom Plus Plan €647.10

Description

Overview

DJI RS 5 features touchscreen subject selection with the new tracking module, smooth balancing from fine-tuning knobs, and direct control via the new briefcase handle all backed by faster charging and extended battery life.

RS Enhanced Intelligent Tracking Module

The module lets you frame and track any subject from the gimbal's touchscreen, keeping it precisely positioned. And when tracking a person, it offers a range of up to 10 meters and can reacquire the subject if they temporarily leave the frame.

Next-Gen Algorithm, Enhanced Torque

Peak motor torque is up by 50% over the previous model, offering stability in fast-moving scenes. The 5th-Gen RS Stabilization Algorithm further enhances stabilization for walking, running, and vertical shooting, striking an ideal balance between stability and control.

Compact Body With up to 3kg Payload

The gimbal weighs just 1.46 kg with battery grip and quick-release plates, and switches to vertical shooting without extra accessories. With a robust 3kg (6.6lbs) payload capacity, it can carry mainstream mirrorless camera and lens combinations with ease.

New Electronic Briefcase Handle

The new Electronic Briefcase Handle offers intuitive, effortless single‑handed operation, featuring a joystick and buttons that control the gimbal and camera for more creative angles.

Longer Runtime, Fully Charged in 1 Hour

Fully charge DJI RS 5 in just one hour—a 60% increase in speed. The standard battery delivers approximately 14 hours of standby time, a 15% improvement.

DJI RS BG70 High-Capacity Battery Grip

The new BG70 High-Capacity Battery Grip can extend RS 5's battery standby time to 30 hours.

New Bluetooth Shutter Support for Panasonic & Fujifilm

In addition to cameras from Sony, Canon, and Nikon, the RS 5's Bluetooth shutter now supports specific Panasonic and Fujifilm cameras, enabling wireless control of shutter, zoom, and Clear Image Zoom with no cables required.

Z-Axis Indicator

The new Z‑Axis Indicator gives you instant feedback to fine‑tune your footsteps for steadier, more professional shots.

Smooth & Precise Balancing

Fine-tuning knobs on each axis arm enable quick, precise balancing through a leadscrew mechanism. Combined with Teflon™ interlayers, RS 5 delivers smooth and precise balancing even with heavier professional setups.

2nd-Gen Automated Axis Locks

The 2nd-Gen Automated Axis Locks automatically lock the gimbal upon power-off or sleep for easier transitions and storage. They unlock just as quickly upon power-on, getting you ready to film in an instant for those critical moments.

3rd-Gen Native Vertical Shooting

To switch to vertical shooting, simply loosen and press the single-side knob, remove the gimbal's horizontal plate, rotate it 90°, and then tighten it back in place all in just a few seconds.

Dual-Layered Quick-Release Plates

The Arca-Swiss upper plate and Manfrotto lower plate allow quick switching between gimbal and tripod without rebalancing, thanks to position memory. In addition, the upper plate features an adjustable guide for secure camera mounting.

Specifications

Peripheral

Accessory Port

Ronin Series Accessories (RSA)/NATO Ports
1/4"-20 Mounting Hole
Cold Shoe
Camera Control Port (USB-C)
Multifunctional Port (USB-C)

Battery

Model: BHX715-2150-15.48
Type: LiPo 4S
Capacity: 2150 mAh
Energy: 33.29 Wh
Voltage: 11.2 V to 17.8 V
USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
Max Standby Time: Approx. 14 hours
Charging Time: Approx. 1 hour
Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

Connections

Bluetooth 5.0
USB-C Charging Port

Ronin App Requirements

iOS 14.0 or above
Android 9.0 or above

Languages Supported by the Touchscreen

English
Simplified Chinese
Traditional Chinese
German, French
Korean
Japanese
Spanish
Portuguese (Brazil)
Russian
Thai

Working Performance

Tested Payload

3.0 kg (6.6 lbs)

Maximum Controlled Rotation Speed

Pan: 360°/s
Tilt: 360°/s
Roll: 360°/s

Mechanical Range

Pan Axis: 360° continuous rotation
Roll Axis: -95° to +240°
Tilt Axis: -112° to +214°

Axis Lock: Auto

Vertical Shooting: Supported

Mechanical & Electrical Properties

Operating Frequency: 2.4000-2.4835 GHz

Bluetooth Transmitter Power: < 8 dBm

Operating Temperature: -20° to 45° C (-4° to 113° F)

Weight

Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
Grip: Approx. 274 g (0.6 lbs)
Quick-Open Tripod: Approx. 149 g (0.3 lbs)
Upper and Lower Quick-Release Plates: Approx. 96 g (0.21 lbs) (including screws)

Dimensions

Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod)
Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod)

Accessories

DJI RS Enhanced Intelligent Tracking Module

Weight: Approx. 19 g (0.04 lbs)
Dimensions: 36.3×17.5×38.2 mm (L×W×H)
Tracking Distance: 0.5-10 m
Operating Environment: Illuminance > 20 lux
Trigger Methods: Gimbal trigger, gesture, gimbal touchscreen
Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
Power Consumption: Approx. 1 W
Operating Temperature: -10° to 45° C (14° to 113° F)
Mounting Method: Magnetic attachment

Electronic Briefcase Handle

Weight: Approx. 230 g (0.51 lbs)
Dimensions: 60×197.5×79.5 mm (L×W×H)
Standby Power Consumption: Approx. 0.2 W
Operating Temperature: -20° to 45° C (-4° to 113° F)
